| Product Specs |
| FORM FACTOR |
ATX |
| SOCKET TYPE |
LGA 1151 |
| COMPATIBLE PROCESSORS |
Intel® Celeron®, Intel® Core™ i3, Intel Core i5, Intel® Pentium® |
| CHIPSET |
Intel® Q270 |
| MEMORY STANDARD |
DDR4-SDRAM
Supported memory clock speeds: 2133,2400 MHz |
| MEMORY SLOTS |
2 |
| MEMORY CHANNELS |
Dual-channel |
| MAXIMUM INTERNAL MEMORY |
32 GB |
| PORTS |
Ethernet LAN (RJ-45) ports: 1
HDMI ports quantity: 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 2
USB 2.0 ports quantity: 4
PS/2 ports quantity: 2 |
| ETHERNET |
Gigabit Ethernet |
| ONBOARD USB 2.0 |
1 |
| ONBOARD USB 3.1 |
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1 |
| M.2 SLOTS |
1 |
| SATA III CONNECTORS |
4 |
| FRONT PANEL AUDIO |
1 |
| MAIN POWER CONNECTOR |
24-pin |
| CPU FAN CONNECTOR |
1 (4-pin) |
| CHASSIS FAN CONNECTORS |
2 x Chassis Fan Connectors (4-pin) (Smart Fan Speed Control) |
| TPM |
1 |
| AUDIO CHIPSET |
Realtek ALC897 |
| AUDIO CHANNELS |
7.1 channels |
| PCI EXPRESS X1 |
12 |
| PCI EXPRESS X16 |
1 |
| RAID |
0,1,5,10 |
| WIFI |
Intel® I219-V |
| RESOLUTION |
Supports HDMI 1.4 with max. resolution up to 4K x 2K (4096x2160) @ 24Hz / (3840x2160) @ 30Hz |
| WAKE-ON-LAN READY |
Yes |
| CHASSIS INTRUSION CONNECTOR |
1 x Chassis Intrusion and Speaker Header |
| DIMENSIONS |
Width: 305 mm
Depth: 208 mm |
ASRock
