| Product Specs |
| POWER PROVIDED |
750W |
| FORM FACTOR |
PC ATX |
| MTBF |
100,000 hours |
| INPUT VOLTAGE |
230VAC |
| OUTPUT CONNECTORS |
1 x 20+4-pin ATX
1 x 4+4-pin 12V ESP/CPU
1 x 6-pin, 1 x 6+2-pin PCIe
3 x 4-pin peripheral
8 x 5-pin SATA |
| VOLTAGE PROVIDED |
+3.3V (22A)
+5V (22A)
+12V (38A)
-12V (0.3A)
+5VSB (3A) |
| FANS |
135mm temperature and load controlled double ball-bearing fan |
| FEATURES |
Single +12V Rail
Continuous output rated at 40°C
High Efficiency: 85% at typical load, meets 80+ Bronze standards |
| DIMENSIONS |
150mm x 160mm x 86mm |
| WEIGHT |
1.7kg |
| WARRANTY |
3 years OCZ Power Swap Warranty |
|
|
|
