| Product Specs |
| FORM FACTOR |
Full Tower |
| MOTHERBOARD COMPATIBILITY |
ATX, EATX, Micro ATX |
| POWER SUPPLY |
ATX |
| RADIATOR COMPATIBILITY |
Front: Up to 240mm
Top: Up to 480mm / with 140mm Radiator then up to 420mm
Side: Up to 240mm
Rear: 120 / with 140mm Radiator then up to 140mm
Bottom: Up to 480mm / with 140mm Radiator then up to 280mm |
| COLOR |
Black |
| SIDE PANEL WINDOW |
Split window design |
| FRONT PORTS |
2x USB 3.0, 2x USB 2.0, Mic, Headphone, LED Switch, Reset |
| MAX GPU LENGTH |
51.5 cm |
| MAX CPU COOLER HEIGHT |
20.7 cm |
| EXTERNAL 5.25 |
5 |
| INTERNAL 3.5 |
6 |
| INTERNAL 2.5 |
12 |
| EXPANSION SLOTS |
8 |
| PORTS |
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 2 |
| FRONT FANS INSTALLED |
2 x 140mm |
| FRONT FANS SUPPORTED |
4
Front fans diameters supported: 120,140mm |
| TOP FAN DIAMETERS |
120,140mm |
| TOP FANS SUPPORTED |
7 |
| REAR FAN SUPPORTED |
Rear fans diameters supported: 120,140mm
Rear fans installed: 1x 140mm |
| REAR FAN INSTALLED |
1x 140mm |
| BOTTOM FAN SUPPORTED |
6 |
| BOTTOM FAN DIAMETERS |
120,140mm |
| MATERIAL |
Aluminium, Steel |
| DIMENSIONS |
Width: 250 mm
Depth: 600 mm
Height: 650 mm |
| WEIGHT |
Weight: 17.9 kg |
| WARRANTY |
5 years manufacturers warranty |
|
|
|
Phanteks
