| Product Specs |
| CAPACITY |
1TB |
| INTERFACE TYPE |
PCIe Gen5 x4 |
| FORM FACTOR |
M.2 2280 |
| DATA TRANSFER RATES |
Read speed: Up to 14,000 MB/s
Write speed: Up to 13,000 MB/s |
| RANDOM READ (4K) IOPS |
Random read (4KB): 2000000 IOPS |
| RANDOM WRITE (4K) IOPS |
Random write (4KB): 1650000 IOPS |
| FLASH STORAGE DETAILS |
3D NAND |
| CONTROLLER |
SM2508 |
| OPERATING TEMPERATURE |
Operating temperature (T-T): 0 - 70 °C
Storage temperature (T-T): -40 - 85 °C |
| MTBF |
2,000,000 h |
| SHOCK RESISTANCE |
1,500G/0.5ms |
| SPECIAL FEATURES |
Security algorithms: TCG Pyrite
ECC: Yes |
| DIMENSIONS |
80 x 22 x 4.5mm / 3.15 x 0.87 x 0.18inch (w/ heatsink)
80 x 22 x 3.2mm / 3.15 x 0.87 x 0.13inch (w/o heatsink) |
| WEIGHT |
12g / 0.42oz (w/ heatsink)
8g / 0.28oz (w/o heatsink) |
| PACKAGING |
Retail packaging |
| WARRANTY |
5 years manufacturers warranty |
Adata
