1TB AData XPG SX6000 Pro PCIe Gen3x4 M.2 2280 Solid State Drive

Manufactured by: Adata
This product has been discontinued

Product Information

Part Number: ASX6000PNP-1TT-C
Item No: 17264
Shipping Weight: 0.1 kgs (0.22 lbs)
Actual Weight: 0.03 kgs (0.07 lbs)

Specifications

CAPACITY
1TB
INTERFACE TYPE
NVMe PCIe
FORM FACTOR
M.2 2280
DEVICE TYPE
SSD
DATA TRANSFER RATES
Read speed up to 2100MB/sec
Write speed up to 1500MB/sec
RANDOM READ (4K) IOPS
250000 IOPS
RANDOM WRITE (4K) IOPS
240000 IOPS
FLASH STORAGE DETAILS
3D NAND
CONTROLLER
Realtek
OPERATING TEMPERATURE
Operating temperature (T-T): 0 - 70 °C
Storage temperature (T-T): -40 - 85 °C
MTBF
2000000 h
SHOCK RESISTANCE
1500G/0.5ms
DIMENSIONS
Width: 22
Depth: 80
Height: 2.15
WEIGHT
8 g
PACKAGING
Retail packaging
WARRANTY
5 years manufacturers warranty

Product Description

Boot, load, and transfer faster with the XPG SX6000 Pro PCIe Gen3x4 M.2 2280 solid state drive (SSD). With support for NVMe 1.3 and equipped with 3D NAND Flash, it offers up to 4 times faster performance than SATA SSDs and up to 2TB of capacity. What’s more, the SX6000 Pro is slimmer than standard M.2 2280 SSDs for a higher level of compatibility thanks to its single-sided design.

The Faster the Better
Featuring HMB (Host Memory Buffer) and SLC Caching, the SX6000 Pro accelerates read/write speeds up to 2100/1500MB/s and delivers random performance of up to 250K/240K IOPS. Whether booting, gaming or transferring large files, the SX6000 Pro accomplishes them quickly and effectively.

LDPC ECC for Improved Data Integrity
The SX6000 Pro supports LDPC (Low-Density Parity-Check) error correcting code technology to detect and fix a wider range of data errors for more reliable data transfers and a longer product lifespan.

Single-Sided Design for Easier Installation
Featuring a single-sided design that’s 2.15mm thick, the SX6000 Pro is much slimmer than standard M.2 SSDs. This makes it ideal for notebooks, small-form-factor desktops, and even some ultrabooks.

Cool XPG heatsink included
The SX6000 Pro box has a sleek black XPG heatsink with pre-applied thermal compound inside for easy DIY. With or without heatsink : the choice is yours, as the SX6000 Pro looks great in builds either way.
