| Product Specs |
| FORM FACTOR |
ATX |
| SOCKET TYPE |
LGA 1700 |
| COMPATIBLE PROCESSORS |
Intel® Celeron®, Intel® Core™ i3, Intel Core i5, Intel Core i7, Intel Core i9, Intel Pentium G |
| CHIPSET |
Motherboard chipset: Intel Z690
Motherboard chipset family: Intel |
| MEMORY STANDARD |
DDR5-SDRAM
Supported memory clock speeds: 6200,4800,5000,5200,5400,5600,5800,6000 MHz |
| MEMORY SLOTS |
4 |
| MEMORY CHANNELS |
Dual-channel |
| MAXIMUM INTERNAL MEMORY |
128GB |
| PORTS |
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 2
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: 1
Ethernet LAN (RJ-45) ports: 1
S/PDIF out port
HDMI ports quantity: 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 4
USB 2.0 ports quantity: 4
PS/2 ports quantity: 1
DisplayPorts quantity: 1 |
| ETHERNET |
1 x Intel® 2.5Gb Ethernet ASUS LANGuard |
| ONBOARD USB 2.0 |
2 x USB 2.0 headers support additional 4 USB 2.0 ports |
| ONBOARD USB 3.1 |
1 x USB 3.2 Gen 2x2 connector (supports USB Type-C®)
1 x USB 3.2 Gen 1 header supports additional 2 USB 3.2 Gen 1 ports |
| M.2 SLOTS |
3 |
| SATA III CONNECTORS |
6 |
| FRONT PANEL AUDIO |
1 |
| FRONT PANEL CONNECTOR |
1 |
| MAIN POWER CONNECTOR |
24-pin |
| CPU FAN CONNECTOR |
1 x 4-pin CPU Fan header
1 x 4-pin CPU OPT Fan header |
| 4 PIN FAN CONNECTORS |
5 |
| CHASSIS FAN CONNECTORS |
1 x 4-pin AIO Pump header
5 x 4-pin Chassis Fan headers |
| TPM |
1 x SPI TPM header (14-1pin) |
| RGB LED HEADER |
3 x Addressable Gen 2 headers
1 x AURA RGB header |
| AUDIO CHIPSET |
ROG SupremeFX 7.1 Surround Sound High Definition Audio CODEC ALC4080 |
| AUDIO CHANNELS |
7.1 channels |
| RAID |
0,1,5,10 |
| SUPPORTED OPERATING SYSTEMS |
Windows 10, Windows 11 |
| THUNDERBOLT |
1 |
| BLUETOOTH |
ver 5.2 |
| WIFI |
Wi-Fi 6E (802.11az) |
| DIMENSIONS |
Width: 305 mm
Depth: 244 mm |
ASUS
