| Product Specs |
| FORM FACTOR |
Micro ATX |
| SOCKET TYPE |
Processor socket: PGA 1331
Supported processor sockets: Socket AM4 |
| CHIPSET |
AMD X570 |
| MEMORY STANDARD |
Supported memory types: DDR4-SDRAM
Supported memory clock speeds: 2666,3200 MHz |
| MEMORY SLOTS |
4 |
| MAXIMUM INTERNAL MEMORY |
32GB |
| PORTS |
5 x Ethernet LAN RJ-45
1 x HDMI
2 x USB3.2 Gen 1 (3.1 Gen 1) Type-A
1 x VGA (D-Sub) |
| ETHERNET |
10 Gigabit Ethernet LAN |
| M.2 SLOTS |
M.2,SATA III |
| SATA III CONNECTORS |
12 |
| MAIN POWER CONNECTOR |
ATX Power connector (24-pin) |
| TPM |
TPM connector |
| PCI EXPRESS X1 |
1 x PCI Express x1 |
| PCI EXPRESS X16 |
1 x PCI Express x16 (Gen 4.x) |
| RAID |
RAID levels: 0,1,10 |
| WIFI |
Intel I210, Intel X550-AT2 |
| CHASSIS INTRUSION CONNECTOR |
Chassis intrusion connector |
ASRock
