| Product Specs |
| INTERNAL / EXTERNAL |
Internal |
| AUDIO OUTPUT CHANNELS |
5.1 discrete surround for speakers
7.1 virtual surround for headphones |
| AUDIO QUALITY |
Up to 32-bit / 384 kHz extreme audio fidelity |
| SIGNAL-TO-NOISE RATIO |
127 dB |
| HOST INTERFACE |
PCI-e |
| MICROPHONE IN |
Mic-in: 16-bit / 16.0, 44.1, 48.0, 88.2, 96.0 kHz, 24-bit / 44.1, 48.0, 88.2, 96.0 kHz, 32-bit / 44.1, 48.0, 88.2, 96.0 kHz |
| LINE-IN |
1 x 3.5 mm Mic / Line-in
AUX-in: 16-bit / 44.1, 48.0, 88.2, 96.0 kHz, 24-bit / 44.1, 48.0, 88.2, 96.0 kHz |
| LINE OUT |
3 x 3.5 mm 5.1 Line-out |
| HEADPHONE OUTPUTS |
1 x 3.5 mm |
| OPTICAL OUT |
1 x TOSLINK Optical-out
16-bit / 44.1, 48.0, 88.2, 96.0 kHz, 24-bit / 44.1, 48.0, 88.2, 96.0 kHz |
| FEATURES |
Audio Technologies:
CrystalVoice
Scout Mode
DTS Connect Encoding
Dolby Digital Live Encoding
Headphone Amp:
Output Impedance: 1Ω, Supported Headphone Impedance: 16–600Ω, IEM: 16–31Ω (1.9V RMS), Normal: 32–149Ω (3V Rms), High Gain: 150–600Ω (5.6V Rms) |
| RECOMMENDED USAGE |
Gaming |
| DIMENSIONS |
Width: 145 mm
Depth: 20 mm
Height: 128 mm |
| WARRANTY |
1 years manufacturers warranty |
|
|
|
