EVGA 500W ATX Semi Modular Power Supply - Black
Manufactured by:
Product Information
Part Number: 110-BQ-0500-K1
Item No: 281-0097
Shipping Weight: 0.5 kgs (1.1 lbs)
Actual Weight: 0.5 kgs (1.1 lbs)
Specifications
POWER PROVIDED
500 W
FORM FACTOR
ATX
INPUT VOLTAGE
100 - 240 V
INPUT FREQUENCY
50 - 60Hz
MOTHERBOARD CONNECTOR
24-pin ATX
CPU POWER CONNECTOR
CPU power connector (4+4 pin)
SATA POWER CONNECTOR
6
PERIPHERAL (MOLEX) POWER CONNECTOR
3
PCI EXPRESS CONNECTOR
2
FANS
1 fan(s)
FAN DIAMETER
12cm
POWER PROTECTION FEATURES
Over current, Over voltage, Short circuit, Under current
MODULAR
Modular
COLOR
Black
ENERGY EFFCIENCY
80 PLUS Bronze
MTBF
100000 h
Product Description
Introducing the next generation in value; the EVGA BQ Series. These power supplies take some of the best features from EVGA's award winning power supply lineup, like near silent operation and modular cables to make one of the best values today in high performance power supplies.
500W Power Supply
Delivers the power needed to run your PC.
Ultra Quiet
Quiet and Intelligent Auto Fan for near-silent operation
Heavy duty protections
Over Voltage Protection, Under Voltage Protection, Over current protection, over power protection, short circuit protection, over temperature protection
80 PLUS Bronze-certified design
With up to 85% energy efficiency reduces excess heat and helps conserve energy.
Single +12V rail
Offers compatibility with a wide range of components.
